Wave Spring 68E Single Mechanical Seal Speed Less 25m/S

Minimum Order Quantity : 5PC Price : Negotiated
Packaging Details : box as requirement Delivery Time : 20-30DAYS
Payment Terms : T/T, Western Union, L/C Supply Ability : 100000PC/Month
Place of Origin: MADE IN CHINA Brand Name: JR
Certification: ISO9001 Model Number: 68E

Detail Information

Material: SIC SIC FKM CAR CER NBR Function: For Oil Pump, Water Pump
Transport Package: Box HS Code: 848420090
Specification: 68E Certificate: ISO9001
Type: For Aesseal W04 Seal Johnson Classic Seal Standard: Standard
Style: Mechanical Seal Product Name: Aesseal W04 Seal Roplan RT73 Seal Sterling 280Y Seal Johnson Classic Seal
High Light:

25m/S Single Mechanical Seal

,

68E Single Mechanical Seal

,

68E Single Spring Mechanical Seal

Product Description

Single Wave Spring Mechanical Seal 68E For Aesseal W04 Seal Roplan RT73 Seal Sterling 280Y Seal Johnson Classic Seal



Operational Conditions:

  1. Aesseal W04 seal
  2. Roplan RT73 seal
  3. Temperature: -40ºC to +250ºC
  4. Pressure: ≤1.5MPa
  5. Speed: ≤25m/s

 Materials:

  • Stationary Ring: Ceramic, Silicon Carbide, TC
  • Rotary Ring: Carbon, Silicon Carbide
  • Secondary Seal: NBR, EPDM, FKM, PTFE
  • Spring and Metal Parts: Steel

Performance Capabilities

sulzer pump Aesseal W04 seal 68E mechanical seal rotary seal mixer seal
Operational Condtions
Size
Material
Temperature:
-40℃ to 200℃ dependent on the elastomer
30mm to 80mm
Face: Carbon, SiC, TC
Pressure:Up to 25 bar
Seat: Ceramic, SiC, TC
Speed:Up to 20 m/s
Elastomer:NBR, EPDM, FKM
End Play /axial float Allowance:±1.0mm
Other Metal Part:SS304 SS316




1.Sterling 280Y seal

Johnson Classic seal

2.Our seals can replace the original seals.

3.If it is not the one you need ,you can pass us your drawing ,material,shaft size for quotation.





Wave Spring 68E Single Mechanical Seal Speed Less 25m/S 0

We are engaged in manufacture and installation exporting and wholesaling quality range of Industrial Seal, Single Spring Seal, Balance and Unbalance Spring Seal, External Mounted Seal, PTFE Bellow External Mounted Seal, Catridge Balance Seal, Multiple Spring Balance Seal, Dry Running Reverse Balance Seal, Agitator Double Acting Unbalance Seal, Single Conical Helical Spring, Rubber Bellow Seal, Multi Spring Seal, Metal Bellow Seal, Elastomer Bellow Seal, Conical Spring Seal, Air Condition Compressor Seal, Auto Cooling Seal, Metallic Bellow Seal,



All ranges of mechanical seals for Flygt Pumps, Grundfos Pumps, Pumps, APV Pumps, Grindes Pumps, Fristam, ABS, Alleeiler, EMU, GEA

Tunchenhagen, Godwin, Hidrostal, Hilge, Johnson, Lowara, Waukesha, Vogelsang Pumps etc.



At the meantime, we could manufacture seals according to your sample or drawing, and design as your request
